MS Adjustable Scaffolding Props

Get a Price/Quote

Product Details:

Pin Other
Technique Other
Constitute other
Prop Head Other
Sleeve size Standard sleeve size for secure adjustment
Product Type Adjustable scaffolding prop
Material High-grade mild steel (MS)
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

MS Adjustable Scaffolding Props Product Specifications

Sleeve size Standard sleeve size for secure adjustment
Height Adjustable height ranging from 2m to 4m Meter (m)
Thickness Outer tube: 2.5-3mm Inner tube: 2-2.5mm Micrometers (um)
Material High-grade mild steel (MS)
Prop Head Other
Components Other
Width Base and head plate widths: 150mm to 220mm Meter (m)
Platform Loading Capacity 1 to 2 tons approximately Long Ton
Diameter Outer tube: 60mm Inner tube: 48mm Meter (m)
Application Other
Constitute other
Product Type Adjustable scaffolding prop
Technique Other
Length Customizable based on application Meter (m)
Pin Other
Surface Treatment Powder-coated or galvanized finish

Product Description

MS Adjustable Scaffolding Props are robust and versatile construction tools designed for reliable support in slabs, walls, and columns. Featuring an adjustable prop design, these scaffolding props ensure ease of height customization ranging from 2m to 4m to suit various projects. Crafted from high-grade mild steel (MS) using welded and precision-engineered techniques, they guarantee durability and stability. With a powder-coated or galvanized finish, these props resist corrosion and wear, enhancing their lifespan in demanding construction environments. The design incorporates heavy-duty steel pins, standard sleeve sizes for secure adjustment, and sturdy components such as outer and inner tubes, base plates, head plates, and sleeves. The outer tube measures 60mm in diameter with 2.5-3mm thickness, while the inner tube is 48mm in diameter with 2-2.5mm thickness, ensuring robust structural support. Flat head and U head options are available to accommodate diverse application needs. With a platform loading capacity of approximately 1 to 2 tons, MS Adjustable Scaffolding Props are ideal for heavy-duty construction projects. Base and head plates widths range from 150mm to 220mm, providing sturdy and adaptable support for varying construction requirements. These props can also be customized in length based on specific application demands.
